Dual-Quaternions..

Numbers working together in a unified mathematical form ...





Dual-Quaternions > The Math Behind Dual-Quaternions


Dual-quaternions are a mathematical tool used in computer graphics and robotics to represent transformations, such as rotations and translations, in three-dimensional space. They are an extension of quaternions, which are themselves an extension of complex numbers. Just as complex numbers have a real part and an imaginary part, quaternions have a real part and three imaginary parts. Similarly, dual-quaternions have a real part and a dual part.


dual-quaternions construct structures and do more than their individual parts
Like Acrobatic Gymnastics - dual-quaterniosn can be connected together in unique ways to create innovative and original ways of solving problems.


Dual-quaternions are make up of 8 float point numbers (i.e., two quaternions - as each quaternion is 4 floating point numbers).

With dual-quaternions, you can pack lots of information into one neat package. It's like having a single ticket for a ride that includes dancing, spinning and shifting around in space!

A dual-quaternion is represented as:

\[
q = q_r + \varepsilon q_d
\]

where \(q_r\) is the real part, \(q_d\) is the dual-part, and \(\varepsilon\) is the dual-unit, such that \(\varepsilon^2 = 0\) and \(\varepsilon \neq 0\).

The real part of a dual-quaternion represents the rotation, while the dual part represents the translation. Combining these two aspects allows dual-quaternions to represent rigid body transformations in a compact and efficient manner.

To understand the math behind dual-quaternions, it's crucial to grasp their algebraic properties, such as addition, multiplication, and normalization. Addition and multiplication of dual-quaternions follow certain rules, similar to those for complex numbers and quaternions, but with adaptations to incorporate the dual-part.

Dual-quaternions are particularly useful in robotics for representing the motion of rigid bodies, as they can efficiently handle both rotational and translational transformations in a single mathematical entity. They have applications in areas such as animation, computer-aided design (CAD), and robot kinematics. Despite their complexity, dual-quaternions provide a powerful and elegant framework for handling spatial transformations in three-dimensional environments.

An analogy of something like dual-quaternions are 'matrices' or 'vectors' - we use a single vector 'v' to represent a direction or a position (composed of an x, y and z), or a quaternion 'q' to represent an axis and angle. The dual-quaternion `$$\zeta$$` is a single numer for representing both rotation and translation.
