Quick introduction in to basic fluid (and gas) dynamics with a practical emphasis (not just theory but actually implementing and seeing things work).

Keywords: smoke, gas, dynamics, grid, simulation, real-time, animation, vortex, diffuse

Fluids are really cool and also very common - they're all around you! The human body is 65% water, and the Earth is 2/3 water.. while gasses are like fluids brother - they have a very similar set of properties - like air, smoke and clouds.

If you drop in in water or watch smoke float up into the sky - I'm sure you noticed the patterns of similarity?

Anyhow, fluid and gas dynamics are all around you! The're magical and beautiful - and you can emulate their characteristics in code.

So how do you go about simulating these things? Is it hard?

Well fluid dynamics is a big area! With lots of different models - with levels of accuracy and computation cost - however, for the most part of this tutorial I'll focus on `visually' realistic simulations that make numerical approximations. Looks and moves correctly! Also fast and we can interact with it in real-time.


Fluids and gases are everywhere! They
Fluids and gases are everywhere! They're inside you, they're all around you, they are both simple and complex. Their beauty and magic in static and dynamic form are beyond words.


Few concepts and their details - which we're going to try and include:

Diffusion: In a cup of tea, sugar molecules diffuse from areas of high concentration to low concentration, sweetening the drink evenly.
Vortex: A whirlpool forms when water rushes down a drain, creating a swirling vortex of water.
Buoyancy: A ship floats because its weight is less than the weight of water it displaces, thanks to buoyancy.
Viscosity: Honey flows slowly due to its high viscosity, resisting deformation and sticking to surfaces.


Simple Discrate Fluid/Gas Simulation Demo


The code uses JavaScript for the fluid/gas dynamics - as it's easy to follow and can run anywhere (just need a web browser). Focus on 2D simulations - so that it doesn't get overy complex. But it should be enough to show swirly ink-like animation patterns.

The concept implementation has been broken down into key functions - each performing a specific task (like diffusion and buoyancy).

The full code is also implemented on a demo page (LINK).




Smoke and Gas Simulation Output - screenshot from smoke.xbdev.net - test the demo out live.
Smoke and Gas Simulation Output - screenshot from smoke.xbdev.net - test the demo out live.




The following gives the full working code (simplfied) that can run from a single file (no external libraries or resources required).

<!DOCTYPE html>
<
html lang="en">
<
head>
<
meta charset="UTF-8">
<
meta name="viewport" content="width=device-width, initial-scale=1.0">
<
title>Fluid and Gas Dynamics Simulation XBDEV Educational Tech Demo</title>
<
style>

canvas {

border1px solid black;
    }
</
style>
</
head>
<
body>
<
canvas id="canvas" width="400" height="400"></canvas>
<
script>

// Get the canvas element and its context

const canvas document.getElementById('canvas');
    const
ctx canvas.getContext('2d');


// Define the size of the grid

const resolution 2.0;
    const
cols canvas.width resolution;
    const
rows canvas.height resolution;


// Create arrays to hold the density, u velocity, and v velocity

let density = new Array(cols).fill(0).map(() => new Array(rows).fill(0));

let u = new Array(cols).fill(0).map(() => new Array(rows).fill(0));

let v = new Array(cols).fill(0).map(() => new Array(rows).fill(0));


// Initialize density with a letter pattern

const letter "G"// Change the letter here

ctx.font "bold 150px Arial";

ctx.fillText('X'50150);


// Convert the letter on canvas to the density array

const imageData ctx.getImageData(00canvas.widthcanvas.height);
        for (
let i 0colsi++) {
            for (
let j 0rowsj++) {
                if (
imageData.data[(imageData.width) + (4) + 3] > 128
                {

density[i][j] = 1.0;
                }

            }
        }


// initial velcoity

for (let i 0colsi++) {
        for (
let j 0rowsj++) {
            const
resolution canvas.width 2;
            const
resolution canvas.height 2;

// Introduce some randomness to the velocity initialization

u[i][j] = Math.cos*  cols ) * Math.sincols ) * 0.1;

v[i][j] = Math.sin16 cols ) * Math.sincols ) * 0.5;
        }
    }



// Function to update the simulation

function update() {

// Apply diffusion

let diff 0.01;

diffuse(diffu);

diffuse(diffv);


applyBuoyancy(densityv);


// Apply curl

curl();


// Advect density

advect(densityuv);


// Draw the updated fields

render();


// Request animation frame for continuous update

requestAnimationFrame(update);
    }



// Function to apply diffusion

function diffuse(difffield) {
        const
dt 0.1// Time step

const visc 0.0001// Viscosity

const amount dt visc * (cols 2) * (rows 2) * diff;

        for (
let k 010k++) { // Iterations for stability

for (let i 1cols 1i++) {
                for (
let j 1rows 1j++) {

field[i][j] = (field[i][j] + amount * (

field[1][j] + field[1][j] +

field[i][1] + field[i][1])) / (amount);
                }
            }
        }
    }


// Function to apply buoyancy force

function applyBuoyancy(densityv) {
        const
gravity 0.05// Strength of gravity

const buoyancyAlpha 0.1// Buoyancy coefficient for density difference

const buoyancyBeta 0.1// Buoyancy coefficient for vertical velocity

const ambientTemperature 0// Ambient temperature


for (let i 0colsi++) {
            for (
let j 0rowsj++) {
                const
densityDifference density[i][j] - ambientTemperature;
                const
buoyancyForce = -buoyancyAlpha densityDifference buoyancyBeta v[i][j];


// Apply buoyancy force to vertical velocity

v[i][j] += buoyancyForce gravity;
            }
        }
    }





// Function to apply curl

function curl() {
        const
dt 0.1// Time step

const curlCoefficient 1.0;

        for (
let i 1cols 1i++) {
            for (
let j 1rows 1j++) {
                const
du_dy = (u[i][1] - u[i][1]) / (resolution);
                const
dv_dx = (v[1][j] - v[1][j]) / (resolution);

                const
curl dv_dx du_dy;

u[i][j] += -curl dt curlCoefficient;

v[i][j] +=  curl dt curlCoefficient;
            }
        }
    }



// Function to advect the density field
function advect(fielduv) {
    const
dt 0.1// Time step


const temp = new Array(cols).fill(0).map(() => new Array(rows).fill(0));

    for (
let b=0b<7b++)
    for (
let i 1cols 1i++) {
        for (
let j 1rows 1j++) {

let x u[i][j] * dt resolution;

let y v[i][j] * dt resolution;


// Add some diffusion-like behavior
            //x += (Math.random() * 2 - 1) * 0.1; // Introduce random noise in x direction
            //y += (Math.random() * 2 - 1) * 0.1; // Introduce random noise in y direction

            // Clamp advection position to canvas boundaries

if (0.50.5;
            if (
cols 0.5cols 0.5;
            if (
0.50.5;
            if (
rows 0.5rows 0.5;

            const
i0 Math.floor(x);
            const
i1 i0 1;
            const
j0 Math.floor(y);
            const
j1 j0 1;

            const
s1 i0;
            const
s0 s1;
            const
t1 j0;
            const
t0 t1;


field[i][j] = s0 * (t0 field[i0][j0] + t1 field[i0][j1]) +

s1 * (t0 field[i1][j0] + t1 field[i1][j1]);
        }
    }
}





// Function to render the fields

function render() {

ctx.clearRect(00canvas.widthcanvas.height);

        for (
let i 0colsi++) {
            for (
let j 0rowsj++) {
                const
resolution;
                const
resolution;


// Draw density

ctx.fillStyle = `rgba(0, 0, 0, ${density[i][j]})`;

ctx.fillRect(xyresolutionresolution);


/*
                // Draw velocity vectors
                ctx.beginPath();
                ctx.moveTo(x + resolution / 2, y + resolution / 2);
                ctx.lineTo(x + resolution / 2 + u[i][j] * 10, y + resolution / 2 + v[i][j] * 10);
                ctx.strokeStyle = 'blue';
                ctx.lineWidth = 2;
                ctx.stroke();
                */

}
        }
    }


// Start the simulation

update();
</
script>
</
body>
</
html>
